Gawsworth V

  • Multipower Wattage Selectable
  • Suspension kit = GA-SUSKIT
  • Plug in Microwave Available
  • Emergency Pack Available
  • 5 year warranty

High output Multi Power IP65 high bay fitting, designed for high mounting heights in applications including warehouses, sports halls, food factories and public buildings. All models are wattage selectable and are available with Microwave sensing. The Gawsworth’s main body is constructed of black die-cast aluminium with a toughened glass front. 5 year warranty as standard.

Read more

Lighting Design Service is available for this product, please contact the sales office on 01260 292640 or email your drawing to sales@diamondledlighting.co.uk

Downloads

  • Beam Angle
    Beam Angle

    120°

  • Input
    Input

    220-240V

  • Life Hours
    Life Hours

    50,000

  • Dimmable
    Dimmable

    Yes

  • Colour Temperature
    Colour Temperature

    4000K

Part NumberGA5S-150CGA5S-200C
Watt90W, 120W, 150W120W, 160W, 200W
Lumens20400 (max)26400 (max)
Dimensions (mm)∅280 x 158∅330 x 168
Microwave (Plug in)GA5-MW
Microwave Remote ControlGA5-MWRC
Self Test Emergency PackGA5-STEM
