Chatsworth III Pro

Selectable 3CCT & 4 Power
Plug in Internal Microwave/Corridor Function and 3hr Emergency
Polycarbonate construction
Stainless steel clips
Suitable for indoor and outdoor use
Complete with fixing accessories
5 year warranty

IP65 surface mounted non-corrosive fitting. Applications include, industrial areas, garages and warehouses. Three sizes available in single and twin variants. The Chatsworth can be supplied with a combination of optional sensors – Microwave, Emergency, Corridor Function and Dimming.

Downloads

Beam Angle
120°
Input
200-240V
Life Hours
50,000
Dimmable
Available
Colour Temperature
3000K 4000K 6000K

	2ft Single	4ft Single	4ft Twin	5ft Single	5ft Twin	6ft Single	6ft Twin
Part Number	CH3P-2S	CH3P-4S	CH3P-4T	CH3P-5S	CH3P-5T	CH3P-6S	CH3P-6T
Selectable Watt	11W/14W/17W/20W	11W/14W/17W/20W	21W/27W/32W/38W	13W/17W/21W/24W	32W/41W/50W/58W	21W/27W/32W/38W	36W/46W/55W/65W
Max Lumens	3000	3000	5700	3600	8700	5700	9750
Max Power	20W	20W	38W	24W	58W	38W	65W
Dimensions (mm)	650x85x79	1200x85x79	1200x105x79	1500x85x79	1500x105x79	1800x85x79	1800x105x79

Plug in Microwave	LINP-MW
Plug in 3hr Emergency	LINP-EM
Microwave	CH3P-2SMW	CH3P-4SMW	CH3P-4TMW	CH3P-5SMW	CH3P-5TMW	CH3P-6SMW	CH3P-6TMW
3Hr Emergency	CH3P-2SEM	CH3P-4SEM	CH3P-4TEM	CH3P-5SEM	CH3P-5TEM	CH3P-6SEM	CH3P-6TEM
3Hr Emergency & Microwave	CH3P-2SEMMW	CH3P-4SEMMW	CH3P-4TEMMW	CH3P-5SEMMW	CH3P-5TEMMW	CH3P-6SEMMW	CH3P-6TEMMW
